Both Tomick, and the 'Mag' say's the ribs are made from 1mm X 5mm strip, should this not be 2mm X 5mm strip, both the plan and the photo's look like 2mm?? While I'm here I would just like to say that some parts were missing from one of the latest issues, I contacted 'De Ag' and they are sending a replacement 'Mag' straight away, excelent service from 'De Ag', just hope the suplier is as good with their posting! Happy building  , Jeff
|
|
|
Rank: Pro Groups: Joined: 24/08/2009 Posts: 48,827 Points: -13,348
|
Hi Jeff!  Your right another typo should be 2mm x 5mm planks used for the ribs, also the magazine shown the drill holes in a different place to the instruction and if that wasn't bad enough the main mast plan doesn't show the same part as supplied and the hole are again in the wrong place. Tomicks build diary is correct he moved the holes to the correct place this is what I followed, Tomick hadn't said there was a problem with the instructions for the fighting top. The end result is you can't follow the magazine or the plan for the placement of the ribs you will have to work it out yourself! the 1.5mm holes on the side must be left clear so use a drill bit to mark the hole as you fit the rib next to the bit, the smaller 0.7mm holes can be under a rib that’s ok!. Take a look at the post below:- http://forum.model-space...s&m=27852#post27852
Use the plan to help guide you in the placement of the ribs but you will need to move some to keep the side holes clear. The good news is the fore mast plan is correct and can be followed both for the hole placements and the rib placements.
|
|
|
Rank: Pro Groups: Joined: 24/08/2009 Posts: 48,827 Points: -13,348
|
At times we all make typo's including SoB
|
|
|
Rank: Pro Groups: Joined: 24/08/2009 Posts: 48,827 Points: -13,348
|
Very true Tomick! We are not GOD's and so we make errors!!.  The main thing is we find them quick! before we go to far and try to correct them!
|
|
|
 Rank: Beginner Level 1 Groups: Registered
Joined: 08/08/2010 Posts: 9 Points: 30 Location: Handforth
|
Hi all. Could any one please explain what purpose the ribs serve in the fighting top, other than reinforcement of the structure. I have an image of some poor marine attempting to unload his musket while tripping over the ribs and possibly killing one of his officers. Accidentaly of course or am I missing the obvious.
|
|
|
Rank: Pro Groups: Joined: 24/08/2009 Posts: 48,827 Points: -13,348
|
I should imagine they simply part of the construction
|
|
|
Rank: Pro Groups: Registered
Joined: 07/01/2011 Posts: 399 Points: 1,212 Location: Penhill Estate, Western Cape, ZA
|
lol Capt Birdseye, I was wondering that exact same thing. With the scale being what it is these ribs would be 42cm high. Maybe enough to brace oneself in stormy seas?
|
|
|
Rank: Pro Groups: Joined: 24/08/2009 Posts: 48,827 Points: -13,348
|
Looking at this image it does appear to be in keeping with the norm Tomick attached the following image(s):
|
|
|
 Rank: Vice-Master  Groups: Registered
Joined: 13/10/2011 Posts: 851 Points: 2,628 Location: Leeds, Yorkshire
|
According to Longridge, the reinforcing ribs in the fighting top were usually 4 inch wide and about 4.5 inch thick at the rim, tapering towards the hole in the centre. That's a dimension of about 10 cm. When you scale this down, you get a figure of about 1.2 mm. so I would suggest that 2mm x 5mm is the wrong timber to be using.
Mike T
|
|
|
Rank: Pro Groups: Registered
Joined: 29/03/2010 Posts: 202 Points: 569 Location: sunderland
|
Like most on here I have noticed the odd error or misleading photo in the mag, and if it's not too easy to work out ourselves there's alway's Tomick who pulls everything together, however it's his job to show us how to build this work of art, not rewrite the 'mag',but he generaly manages that as well!! There's a few things not quite right, either on the 'mast plans' or the mag, but thats the good thing about this forum, we keep each other right and correct the mag! Ps, I thought I made a mistake once, but I was wrong! "I did'nt" Thank's chap's Jeff
|
|
|
 Rank: Elite   Groups: Unapproved
Joined: 24/05/2010 Posts: 1,761 Points: 5,351 Location: London & Greece
|
Son of Bulwark wrote:Very true Tomick! We are not GOD's and so we make errors!!. The main thing is we find them quick! before we go to far and try to correct them! Rather than pretending they don't exist. John
|
|
|
Rank: Pro Groups: Joined: 24/08/2009 Posts: 48,827 Points: -13,348
|
And making sure you are familiar with the plans and instructions
|
|
|
Rank: Pro Groups: Registered
Joined: 07/01/2011 Posts: 399 Points: 1,212 Location: Penhill Estate, Western Cape, ZA
|
If one assumes that the picture on the front of the magazine is the ship we're building, the picture on the front of nr 27 shows the exposed ribs.
|
|
|
Rank: Beginner Level 1 Groups: Registered
Joined: 08/08/2010 Posts: 9 Points: 30 Location: Handforth
|
Tomick wrote:Looking at this image it does appear to be in keeping with the norm Many thanks for your reply Tomick. Looking at the interesting picture I notice there is a lip around the center, which would trap any rain and make it a pretty bad place to seek any protection from rough seas. Believe you are right, possibly only for strength.
|
|
|
Rank: Pro Groups: Joined: 24/08/2009 Posts: 48,827 Points: -13,348
|
I dare say a few tripped and fell from the mast top as a result, or when trying to dodge canon balls and musket shot
|
|
|
 Rank: Super-Elite    Groups: Registered
Joined: 04/04/2010 Posts: 3,955 Points: 11,809 Location: uk
|
I would like to add that I fitted the 1mm.x5mm.and it looks right to me so I left it as it was,the fighting top looks right that way,2mmx5mm would have looked to me a bit too heavy. Current builds: SotS, USS Consitution, San Felipe, D51 loco, HMS Surprise, RB7, Arab Dhow, Jotika HMS Victory Completed builds: HMS Pickel, Thermopylae, Mississipi river boat, Mary Rose, Cutty Sark, San Francisco II, HMS Victory x5, Titanic Lifeboat, Panart HMS Victory Launch, Hachette Titanic, Virginia Schooner, Endeavour Longboat. http://www.model-space.com/gb/
|
|
|
 Rank: Master   Groups: Registered
Joined: 08/07/2010 Posts: 1,036 Points: 3,086 Location: Thetford, Norfolk, UK
|
I agree with you Karl, I settled for 1.5x5mm on mine. I tried the 2x5mm we were supplied with first,but it just seemed like there was not enough of a gap between each rib. The 1.5x5mm looks more 'right' if you know what I mean.
|
|
|
Rank: Pro  Groups: Registered
Joined: 25/08/2010 Posts: 170 Points: 537 Location: Germany
|
To be honest, I still don't get what planks you guys are talking about. If there is a typo in the magazine, it would be nice to know, even if it's weeks ahead.
Could you tell me exactly which issue number and page, which step we have to alter ?
Thanks, TimmMy build diary hereCurrent Build:HMS Victory
|
|
|
Rank: Super-Elite Groups: Registered
Joined: 04/04/2010 Posts: 3,955 Points: 11,809 Location: uk
|
hi timm,we are discussing the fighting top(crows nest or 1st.platform)on the main mast,it is a 'd' shape platform which is between the first part of main mast and the second stage,on top of the platform are small ribs,see mr.t pic,these ribs radiate outwards to the edges,the mag says 5mm.x1mm.it should read 5mm.x2mm.and that's what we are discussing,hope this is clear to you. Current builds: SotS, USS Consitution, San Felipe, D51 loco, HMS Surprise, RB7, Arab Dhow, Jotika HMS Victory Completed builds: HMS Pickel, Thermopylae, Mississipi river boat, Mary Rose, Cutty Sark, San Francisco II, HMS Victory x5, Titanic Lifeboat, Panart HMS Victory Launch, Hachette Titanic, Virginia Schooner, Endeavour Longboat. http://www.model-space.com/gb/
|
|
|
Rank: Vice-Master Groups: Registered
Joined: 20/04/2010 Posts: 545 Points: 1,536 Location: lossiemouth
|
dont think anny marines fell of because nelson would not let musketry up top incase they set fire to the sails and not a way to fight a battle
|
|
|
|
